316 Stainless Steel Pickling Pipe
Certification：ISO, AISI, ASTM, GB, EN, DIN, JIS
Technique：Cold Rolled
Surface Treatment： pickling
Length：3-12m, or Customizable
Od：6-2500mm, or Customizable
Thickness：0.2-80mm
Key advantages of 316 Stainless steel pickling pipe
In the fields of chemical industry, marine engineering, food and medicine, 316 stainless steel pickling pipe has become a key material with its excellent corrosion resistance and smooth surface.
As a 316 austenitic stainless steel pipe treated by pickling process, by removing the surface oxide scale and impurities, the corrosion resistance and appearance quality are significantly improved. It is resistant to high and low temperatures and can work stably at -196℃ to 800℃, with excellent anti-oxidation performance.
316 Pickling Stainless Steel Pipe Stockist
Why choose Us
GNEE supplies TP316 pickled stainless steel pipes that comply with ASTM A312/ASME SA312, EN 10216-5, and ISO 683-13. Custom lengths and special requirements are supported. The chromium and molybdenum content is strictly controlled, and the pipes undergo multiple certifications, including PMI material testing and hydrostatic testing.
Contact us now to get the quotation and technical parameters of 316 stainless steel pickling pipe. Our professional team will provide you with selection suggestions!
316 Pickled Austenitic Stainless Steel Pipe Specifications
| Standard | ASTM A312 / ASME SA312, EN 10216-5, ISO 683-13 |
| Grade | 316 (UNS S31600), 316L (UNS S31603) |
| Surface Finish | AP (Annealed & Pickled), No.4, 2B, Mirror (No.8), BA (Bright Annealed) |
| Form | Round, Square, Rectangular, Hydraulic |
| Size Range | |
| - Seamless Pipe | OD: 5.0 mm – 1219.2 mm (0.197" – 48") Wall Thickness: 0.3 mm – 50 mm |
| - Welded Pipe | OD: 6.0 mm – 914.4 mm (0.236" – 36") Wall Thickness: 0.5 mm – 20 mm |
| Schedule | Sch 5, Sch 10, Sch 40, Sch 80, Sch 160, Sch XS (Extra Strong), Sch XXS |
| Length | Single Random, Double Random, Custom Cut Length (e.g., 6m, 12m) |
| End Type | Plain End (PE), Beveled End (BE), Threaded |
| Chemical Composition | |
| - Carbon (C) | ≤0.08% (316L: ≤0.03%) |
| - Chromium (Cr) | 16.0–18.0% |
| - Nickel (Ni) | 10.0–14.0% |
| - Molybdenum (Mo) | 2.0–3.0% |
| - Other | Mn ≤2.0%, Si ≤0.75%, P ≤0.045%, S ≤0.03%, N ≤0.10% |
| Mechanical Properties | |
| - Tensile Strength | ≥515 MPa (74,700 psi) |
| - Yield Strength | ≥205 MPa (29,700 psi) |
| - Elongation | ≥40% (in 50 mm) |
| - Hardness | Rockwell B ≤95, Brinell ≤217 |
| Physical Properties | |
| - Density | 8,000 kg/m³ |
| - Thermal Conductivity | 16.3 W/m·K (at 100°C) |
| - Melting Point | 1,370–1,398°C |
Wholesale China Factory 316 Stainless Steel Pipe
Customer visit
316 High Precision Seamless Stainless Steel Pipe transportation
