ASTM A511 Stainless Steel Mechanical Tubing
Certification：ISO, RoHS, IBR, AISI, ASTM, GB, EN, DIN, JIS
Shape：round
Technique：Cold Rolled
Surface Treatment：Sanded /Mirror/Hairline Brushed
Thickness：0.3-30mm
out Diameter：8-219mm
Length：5.8/6m or Custom
Stock：in Stock
Sample：Available
Transport Package：Standard Sea-Worthy Packing
ASTM A511 Stainless Steel Mechanical Tubing for Precision Applications
ASTM A511 is the standard specification for seamless and welded mechanical tubing made from austenitic, ferritic, and duplex stainless steels. Unlike ASTM A269 or A312, which are used for pressure applications, A511 tubes are designed specifically for mechanical use-such as in hydraulic systems, aerospace structures, medical instruments, and precision-engineered components.
Advantages
GNEE offers high-quality austenitic stainless steel seamless tubes compliant with ASTM A511 standards, covering popular grades such as 304 (UNS S30400) and 316 (UNS S31600). These tubes provide excellent resistance to atmospheric corrosion, with tensile strength ≥ 515 MPa and yield strength ≥ 205 MPa, and are compatible with ER308/ER316 welding wires. They are well-suited for applications in general mechanical components, food processing pipelines, and light industrial fluid transport systems.
In addition, GNEE's ASTM A511 precision stainless steel tubing supports a range of value-added services, including:
Custom length cutting (tolerance ±3 mm)
Surface polishing (Ra ≤ 0.8 μm)
Solution annealing (1050–1100°C, water quenched)
100% hydrostatic testing
All materials comply with ASTM A511 / ASME standards, and are supplied with EN 10204 3.1 mill test certificates.
ASTM A511 stainless steel tube in Stock
ASTM A511TP304 seamless pipe price per kg
The price per kilogram of ASTM A511 TP304 seamless pipe is mainly affected by the cost of stainless steel raw materials (such as nickel, chromium), specifications and dimensions, tolerance requirements, surface treatment and market supply and demand. If you have any questions, you can contact GNEE in time to answer you!
specification
| Item | Specification |
|---|---|
| Standard | ASTM A511 / ASME SA511 |
| Product Type | Seamless stainless steel mechanical tubing |
| Material Grades | TP304 / TP304L / TP316 / TP316L / TP321 / TP310S |
| UNS Designation | S30400 / S30403 / S31600 / S31603 / S32100 / S31008 |
| Manufacturing Process | Cold drawn or hot finished, followed by heat treatment |
| Outer Diameter (OD) | 6 mm – 114 mm (0.25" – 4.5") |
| Wall Thickness (WT) | 0.5 mm – 10 mm (0.02" – 0.39") |
| Length | 2 m – 8 m (Custom lengths available) |
| Tolerance | OD: ±0.1 mm; WT: ±10% or per customer requirement |
| Surface Finish | Annealed & pickled, polished (Ra ≤ 0.8 μm), bright |
| Heat Treatment | Solution annealed (1050°C – 1100°C), water quenched |
| Mechanical Properties | Tensile ≥ 515 MPa; Yield ≥ 205 MPa; Elongation ≥ 35% |
| Testing | 100% Eddy current or hydrostatic test |
| Certification | EN 10204 3.1 / 3.2 available |
| Applications | Mechanical parts, instrumentation, food processing, fluid systems |
high quality packaging
