What Is 310S Stainless Steel?

310S is a high-chromium, high-nickel austenitic stainless steel standardised as UNS S31008 and as EN 1.4845, X8CrNi25-21. The S suffix identifies the low-carbon version of the 310 grade. With 24-26% chromium and 19-22% nickel, the alloy remains fully austenitic and develops a dense, adherent oxide scale that resists scaling and oxidation at temperatures where 304 and 316 would fail quickly.

Because of that chemistry the grade combines three properties that are rarely found together: good creep strength for continuous high-temperature service, excellent resistance to cyclic oxidation, and useful ductility for fabrication. It is not hardenable by heat treatment and is normally supplied in the annealed and pickled condition.

Chemical Composition and Standards

Element ASTM A240 Type 310 (S31000) ASTM A240 Type 310S (S31008) EN 1.4845
Carbon (C) 0.25 max 0.08 max 0.10 max
Silicon (Si) 1.50 max 1.50 max 1.00 max
Manganese (Mn) 2.00 max 2.00 max 2.00 max
Phosphorus (P) 0.045 max 0.045 max 0.045 max
Sulfur (S) 0.030 max 0.030 max 0.015 max
Chromium (Cr) 24.0-26.0 24.0-26.0 24.0-26.0
Nickel (Ni) 19.0-22.0 19.0-22.0 19.0-22.0

Values are percent by mass. The chromium and nickel ranges are identical across the three columns; only carbon and the residual element limits separate the grades, which is why dual certification of 310 and 310S is not common practice.

Mechanical and High-Temperature Properties

Property Typical value
Tensile strength, annealed 515 MPa min
0.2% proof strength 205 MPa min
Elongation in 50 mm 40% min
Density 7.98 g/cm3
Modulus of elasticity about 200 GPa
Thermal conductivity at 100 C about 14.2 W/m.K
Mean expansion, 0-100 C about 15.9 micron/m.K
Continuous service ceiling about 1150 C in oxidising atmospheres
Intermittent service ceiling about 1035 C

The lower intermittent rating reflects thermal cycling: repeated heating and cooling stresses the protective scale, and resistance to that cycling is what separates high-nickel grades such as 310S from leaner austenitics.

310 and 310S Compared

Carbon. 310 permits up to 0.25% carbon; 310S is capped at 0.08%.

Weldability. The low carbon of 310S resists carbide precipitation in the 425-815 C band, so welded furnace hardware can be placed in service without a post-weld solution anneal.

Strength at temperature. Higher carbon gives 310 marginally better creep strength in some ranges, but the difference rarely justifies the loss of weldability and corrosion resistance.

Standard practice. Most furnace, kiln and heat-treatment specifications call for 310S because of its combination of creep performance and post-weld corrosion resistance.

Fabrication, Machinability and Applications

310S work hardens quickly and machines at a rating commonly quoted at roughly 40-45% of the AISI B1112 free-machining reference, so cutting speeds should be lower than for 304, with rigid tooling, positive rake geometry and generous coolant. Cold forming is possible within moderate reductions, though heavy cold work should be followed by a solution anneal to restore the creep properties needed for high-temperature service.

Welding uses matching 310 filler metal; 309 consumables are used for dissimilar joints to carbon steel. Controlled heat input and interpass temperature limit hot cracking and carbide precipitation.

Typical applications include:

Heat-treatment furnace parts, trays, baskets, retorts, muffles and fixtures.

Radiant tubes, tube supports and burner components in process furnaces.

Annealing covers, boxes and inner covers for batch and continuous lines.

Kiln and cement plant internals, including nozzle rings and calciner hardware.

Thermocouple protection sheaths, high-temperature flue ducting and expansion bellows.

Incinerator components, glass and ceramic production hardware, and refinery high-temperature piping.

FAQ

Q: What is 310S stainless steel used for?
310S is used mainly for high-temperature service: furnace parts, heat-treatment fixtures, radiant tubes, annealing covers, kiln internals, thermocouple sheaths and high-temperature ducting. Its oxidation resistance keeps it working where 304 and 316 would scale away.

Q: What is the difference between 310 and 310S?
Only the carbon level separates them. 310 allows up to 0.25% carbon, while 310S is limited to 0.08%. The lower carbon of 310S gives better weldability and resistance to intergranular corrosion after welding.

Q: What temperature can 310S withstand?
The grade is used continuously in oxidising atmospheres up to about 1150 C and intermittently up to about 1035 C. The lower intermittent figure accounts for scale spalling under repeated thermal cycling.

Q: Is 310S better than 304 for high-temperature work?
Yes for oxidation and creep service. 304 offers better value and formability in ambient and mildly corrosive conditions, while 310S is specified where the operating temperature exceeds roughly 800 C or where sulphur-bearing combustion gases are present.

Q: Is 310S stainless steel magnetic?
In the annealed condition the structure is austenitic and effectively non-magnetic. Cold working or welding can introduce a small amount of ferromagnetic phase and a weak magnetic response.

Q: How machinable is 310S?
Machinability is commonly quoted at roughly 40-45% of the AISI B1112 free-machining reference. Use slower speeds, rigid setups and continuous coolant flow, and expect more rapid tool wear than with 304.
