ASTM A269 TP317 Stainless Steel Cold Drawn Pipe
Shape：Round
Technique：Cold Rolled
Material：Stainless Steel
Thickness：0.5mm-40mm
Diameter：6mm-630mm; 10mm-2000mm.
Length：6000mm, Customize.
ASTM A269 TP317 stainless steel cold drawn pipe Introduction
ASTM A269 TP317 stainless steel cold drawn tube is a stainless steel tube produced in accordance with the American Society for Testing and Materials (ASTM) standards, mainly used in general service areas such as conveying gas, water, oil and other fluids.
SA 269 TP 317 seamless tube
Advantages of ASTM A269 TP317 SS Tubes
ASTM A269 TP317 stainless steel seamless pipe has a 20% higher pitting resistance than 316 stainless steel, and is suitable for extreme corrosion environments such as strong chlorides and high-temperature acid, meeting the needs of high-purity scenarios such as high-pressure systems and food and medicine.
ASTM A269 TP317 precision cold-drawn seamless pipe has a temperature resistance range of -196℃ to 980℃, covering LNG low-temperature transportation to high-temperature treatment of industrial waste gas; it supports small-diameter precision pipe customization and EP polishing and other special treatments, and is suitable for instrumentation and high-end equipment segments.
Why Choose GNEE
GNEE exports TP317 steel pipes to 65 countries and regions around the world every year. The price is 5% lower than other suppliers, the production quality is strictly guaranteed, and there is a professional after-sales service team of 20 people. We will solve any doubts for you and provide project solutions! If you are looking for TP317 seamless pipes, please contact us in time to get a quote!
ASTM A269 TP317 Austenitic alloy steel pipe Specifcation
SA 269 TP 317 Seamless Tube Equivalent
| - | Russia | North America |
|---|---|---|
| STANDARD | WERKSTOFF NR. | UNS NO |
| 317 | 1.4449 | S31700 |
| 317L | 1.4438 | S31703 |
ASTM A269 SS 317 Seamless Tube Chemical Composition
| Element | Content Range (%) |
|---|---|
| Carbon (C) | ≤0.08 |
| Silicon (Si) | ≤1.00 |
| Manganese (Mn) | ≤2.00 |
| Phosphorus (P) | ≤0.045 |
| Sulfur (S) | ≤0.030 |
| Chromium (Cr) | 18.0–20.0 |
| Nickel (Ni) | 11.0–15.0 |
| Molybdenum (Mo) | 3.0–4.0 |
SA 269 Grade TP317 Condenser Tube Mechanical Properties
| Melting Point | 1454 °C (2650 °F) |
|---|---|
| Density | 8.0 gram/centimeter3 |
| Yield Strength (0.2%Offset) | Psi – 30000, MPa – 205 |
| Tensile Strength | Psi – 75000, MPa – 515 |
| Elongation | 35 % |
Tolerance of ASTM A269 Grade 317 Tube
| OD mm | Wall thickness % | Tolerances OD, mm |
|---|---|---|
| 6-30 | +/-10 | +/-0.08 |
| 32-40 | +/-10 | +/-0.15 |
| 42 | +/-10 | +/-0.20 |
ASME SA 269 TP 317L Seamless and Welded Tubing Manufacturer
Customer visit
Packaging of ASTM A269 Stainless Steel 316LN Electropolish Tubes
